CO2DA - Automatic Shaker & CO2 Calculator

AT2E CO₂DA - Automatic Shaker & CO₂ Calculator is a special instrument which is for calculating the carbon dioxide content in the filled drink in glass/PET bottles and cans. The simple operation which also guarantees high reproducibility makes it become a significant equipment of quality control in the beverage industry.

Operation:

• Place the sample drink

• Piercing the sample

• Press the start button to test

• Obtain the carbon dioxide content after shaking

Features:

• Instead of manual shaking, motor shaking guarantees high reproducibility

• Stainless steel design

• High resolution touch screen with user-friendly interface

• Settable shaking speed and time

• High accuracy

• Calculate the CO₂ content automatically and rapidly

• Good repeatability

• Simple and easy piercing & operation

• Applicable for most of the glass bottle, PET bottle and can

Technical specifications:

• Measuring range:

    - CO₂:  0.00 to 9.99 g/l
    - Temperature:  0 to 60 °C
    - Pressure:  0 to 6 bar

• Accuracy:

    - CO₂:  ± 0.5% F.S.
    - Temperature:  ± 0.5% F.S.
    - Pressure:  ± 0.5% F.S.

• Resolution:

    - Temperature: 0.1 °C
    - Pressure: 0.01 bar

• Sample range:

    - Maximum diameter: 120 mm
    - Maximum height: 380mm

• Units:

    - CO₂: g/L, Vol, %b.w, P₂₀[kg/cm²]
    - Pressure: bar, psi
    - Temperature: °C, °F

• Power supply: AC 110 - 240 V   50/60 Hz


• Dimension: 580(L) x 380(W) x 365(H) mm

• Net weight: 30 kg
